Description
Key Features
- Non-handed unit
- Quick and easy to install
- 5 years warranty
- Parallel arm bracket optional
- Finish Customization: Pantone/RAL matched paint.
Door Closer BE SERIES
- Category：Ships door closer Series
- Installation Hole Size: 52x45mm
- Power: EN3-EN7
- Door Weight:405-180kgs
- Door Width: ≤1600mm
Additional information
| BE3NC | EN3 40-65KG |
|---|---|
| BE4NC | EN4 60-85KG |
| BE5NC | EN5 80-120KG |
| BE6NC | EN6 100-150KG |
| BE7NC | EN7 180KG |
| Mechanism | Rack and pinion |
| Adjustable closing speed | Yes |
| Adjustable latching speed | Yes |
| Back check function | No |
| Delay function | No |
| Maximum door width(mm) | 1600 |
| LH and RH doors – universal application | Yes |
